CD Series Indoor Fixed Installation

CD Series is a lightweight & wall-mounting product for indoor fixed installation. Variable installations would be available by combination of 6 different cabinet sizes. CD Series' precise and super thin frame assembly provides a seamless and consistent display. CD series can be adapted to a variety of scenarios, widely used in retail stores, commercial complexes, airport info displays and other places.

  • LIGHTWEIGHT AND THIN
  • VISUAL PERFORMANCE
  • CREATIVE INSTALLATONS
  • MAINTENANCE
  • MULTI ASSEMBLY

Product Features

Multiple frame size options

Variable installation dimensions would be available by combination of cabinets as below 6 sizes.

Lightweight and thin

Lightweight and thin cabinet with a thickness of 40mm, perfectly attached to building walls without the need to cover the screen edges

Front maintenance

Modules /receivers/power supplies and other parts are all front accessible.

Creative installations

CD series supports wall-mounting installation/right angle installation /cubic installation.

Perfect flatness and visual performance

CD series’ precise panel design ensures a perfectly flat & even screen and presents fabulous visual effects.

GOB surface protection optional

The GOB process can achieve waterproof, moisture-proof, bump-proof, dust-proof, corrosion-proof, and anti-static. The matte surface effect also increases the color contrast and wide viewing angle, presenting perfect visual performance.

Product Specifications

Pixel Pitch

P1.953mm

P2.5

P2.604

P2.976

P3.91

LED Type

SMD1515

SMD2020

SMD1515

SMD2020

SMD2020

Pixel Density

262,144dots/m2

160,000dots/m2

147,456dots/m2

112,896dots/m2

65,536dots/m2

Module Resolution

16,384dots

10,000dots

9,216dots

7,056dots

4,096dots

Module Size

250x250mm



Surface Treatment

GOB/Protective mask



Cabinet Resolution

512x128dots

400x100dots

384x96dots

336x84dots

256x64dots

Cabinet Size

1000x250mm/750x250mm/500x250mm  / 1000x500mm/750x500mm/500x500mm

Cabinet Weight

1000*250:5.6kg/750*250:4.2kg/500*250:2.8kg  /  1000*500:10.2kg/750*500:8.2kg/500*500:5.2kg

Cabinet Material

Die-cast aluminum

Refresh Rate

3,840hz



Brightness

800nits

800-1,200nits

800nits

800nits

800nits

Gray Scale

14-22bits



Maintenance

Front

Ave.Power Consumption

160W/㎡

160W/㎡

150W/㎡

115W/㎡

100W/㎡

Max.Power Consumption

500W/㎡

500W/㎡

450W/㎡

350W/㎡

300W/㎡

Operating Power Source

AC 110-220V 50/60Hz



IP Rating

IP43



Signal Input Source

DVI, HDMI 1.3, HDMI2.0, DP 1.2, SDI,etc.



Operating Temperature

-20℃ to 50℃



Operating Humidity

10% to 90%



Screen Lifespan

≥100,000hours
